Home - News
News
Callisto+
UP/DOWN/CROSS CONVERTER
pubblicato giovedì, 20 maggio 2021 da Dario Bruno
Callisto+
Hi there,

Exciting greenMachine news! We've launched callisto+
It's a new piece of hardware to complement the existing greenMachine titan hardware (4K capable).
callisto+ is 2x 3G capable with the same feature set and performance of titan and provides users with a more cost-effective and entry level signal processing solution when 4K is not necessary or required.

The first signal processing configuration available for callisto+ is a broadcast-quality two channel 3G SDI up/down/cross converter

• convert between SD, HD and 3G video formats
• built-in frame synchronizer
• built-in 3G scaler
• built-in de-interlacer with motion adaptive filtering
• embedded metadata management
• color correction for gain, lift and gamma adjustment
• various video adjustment features

Link: https://www.lynx-technik.com/products/greenmachine/video-conversion/2c-upxd-dual-channel-updowncross-converter/
Waveform Monitor WFM 1801
Waveform Monitor And Vectorscope
pubblicato martedì, 18 maggio 2021 da Dario Bruno
Waveform Monitor WFM 1801
WFM 1801 is a handheld, multifunctional waveform monitor ideally suited to the monitoring needs of field production and equipment installation. Installed with rechargeable battery, it adds convienience and efficiency by making the monitoring portable. The combination of Waveform monitoring, Vectorscop and audio monitoring makes this equipment powerful for complex video and audio systems.

Fitted with 5” LCD with capacitative screen, WFM 1801 provides a clear preview of incoming video signals. The display screen provides monochrome waveform, vector and up to 16 channels of audio monitoring with several audio scale selection options. It is also capable of calculating and displaying the SDI error counts,
and SDI cable length measurements. It provides a convienient way to view the SMPTE 352M VPID payload hex values.

When bundled with PTG 1801 test pattern generator, WFM 1801 will provide a complete testing and monitoring solution that fits in the palm of your hand and will your time in field production and equipment installation.

Link: https://www.lynx-technik.com/products/waveform-monitor/wfm-1801-waveform-monitor-and-vectorscope/
RCT 1012 - NEW
Yellobrik Rack Controller
pubblicato venerdì, 14 maggio 2021 da System Admin
RCT 1012 - NEW
Lynx Technik AG is delighted to announce the launch of the yellobrik controller RCT 1012.

This is in answer to many requests for an interface between the mini USB control and configuration socket on applicable yellobriks, and an ethernet network.

The user no longer needs to access each individual yellobrik with a miniUSB lead and laptop to gain access to the internal configuration settings, they can now access yellobriks remotely from anywhere.


Further specifications, Quickreference and Reference Manual can be found here: https://www.lynx-technik.com/products/yellobrik/rack-controllers/rct-1012-yellobrik-rack-controller/
LYNX Technik’s HDR Evie™ Wins NAB Product of the Year Award
The world’s first HDR to SDR conversion solution
pubblicato lunedì, 13 maggio 2019 da System Admin
LYNX Technik’s HDR Evie™ Wins NAB Product of the Year Award
Lynx Technik AG | News | Tuesday, 30 April 2019

April 29, 2019 – Weiterstadt, Germany – LYNX Technik announced today that its HDR Evie™, real-time, frame-by-frame HDR to SDR conversion solution is a Best New Technology winner in the 2019 NAB Show Product of the Year Awards. The inaugural NAB awards recognizes the most significant and promising new products and technologies showcased by Exhibitors at the 2019 NAB Show in Las Vegas, NV.

HDR Evie is an ideal HDR to SDR conversion solution for dynamically demanding and unpredictable content, such as live sports or news broadcasts. It is the world’s first HDR to SDR conversion solution using advanced algorithms which automatically analyze the image content and apply optimal corrections in real time on a frame by frame basis. This unique capability is unlike any solution today and is the perfect real time production tool for environments that have challenging lighting conditions, brightness levels and image composition.

There are available tools on the market, which apply “global correction” across HDR content. However, for truly exceptional results which will automatically adapt for changes in image composition and brightness levels encountered in any production or live event, then frame by frame processing is required. This frame by frame processing is accomplished during a post-production process, which is in non-real-time, expensive and time-consuming.

HDR Evie, powered by greenMachine®, addresses all of these issues by offering an automated, real time and frame by frame HDR to SDR conversion. The technology is both proprietary and patented, following years of research and development in close cooperation with Hochschule RheinMain University of Applied Sciences in Germany.

“HDR Evie solves a challenge for broadcasters that was not previously addressed with an available real-time solution,” comments Stefan Gnann, CEO of LYNX Technik. “We are grateful for this award as it re-confirms the unique value HDR Evie brings to the marketplace in solving the need for dynamic HDR to SDR conversion.

“Nominees like LYNX Technik are revolutionizing the way people experience media and entertainment,” said NAB Executive Vice President of Conventions and Business Operations Chris Brown. “The 2019 NAB Show Product of the Year Awards highlight the best of what’s new at the premier launchpad for breakthroughs at the intersection of media, entertainment and technology.”

More information at: http://www.hdrevie.com/
LYNX Technik Announces Bi-Directional 12G/3G Single-Link/Quad-Link Converter
Yellobrik CQS 1441
pubblicato lunedì, 5 giugno 2017 da System Admin
LYNX Technik Announces Bi-Directional 12G/3G Single-Link/Quad-Link Converter
March 28, 2018 – Weiterstadt, Germany –LYNX Technik AG®, provider of software-defined modular interfaces for broadcast as well as professional AV and industrial signal processing applications, announces its new yellobrik CQS 1441, a bi-directional single-link/quad-link 4K/UHD converter for 12G, 6G, 3G and 1.5G. LYNX Technik will showcase the new yellobrik at NAB 2018 in the IABM member lounge, N110MLR.

The yellobrik CQS 1441 is a compact converter that enables single-link 12G-SDI signals to be converted to quad-link 3G-SDI and visa versa (i.e. quad-link 3G-SDI signals to be converted to single-link 12G-SDI). 6G to/from quad-link 1.5G conversions are also supported.

With many facilities still running in a 3G environment, there are many requirements to integrate 4K/UHD signals in 12G SDI into the infrastructure. The CQS 1441 yellobrik enables users to convert UHD signals between quad-link 3G and single-link 12G SDI. Plus, since its bi-directional, a single yellobrik can be used for both inputs and outputs for the application at hand.

Another key feature of this new yellobrik is its 12G fiber option and a 12G loop output. For example, a 4K UHD camera or other input source can be connected via 12G fiber to the yellobrik’s SFP fiber input and the 12G loop connects the yellobrik to a 12G video mixer for signal switching. The CQS 1441 also offers a 12G fiber to 12G coax conversion feature. Regardless of whether customers choose fiber or SDI, they can have the simplicity of running 4K over a single wire.

The intuitive and user-friendly yelloGUI software gives users access to a host of advanced settings and adjustments of the CQS 1441, as with other compatible yellobriks. With yelloGUI users have an enhanced level of yellobrik configuration for advanced features & settings. yelloGUI is complementary to all yellobrik users.

The CQS 1441 is fully compatible with the unique yellobrik rack frame for high density applications and additional redundancy.

Link: https://www.lynx-technik.com/products/yellobrik/video-conversion/cqs-1441-available-soon-bi-directional-single-link-to-quad-link-converter/
PEC 1864
3G/bits SDI/HDMI to H.264 encoder live streaming & recording.
pubblicato lunedì, 5 giugno 2017 da System Admin
PEC 1864
Pensato per un ampio range di applicazioni in campo broadcast, film e industria audiovisiva.
Il PEC 1864 può registrare e inviare un flusso streaming contemporaneamente. Ogni modulo contiene al suo interno un up/down/cross converter, uno scaler per la regione di interesse e la funzione di "text overlay".
Può de-embeddare due canali audio dal video in ingresso o embeddare nello streaming l'audio presente al suo ingresso indipendente. Nello streaming è anche possibile inserire un logo e posizionarlo liberamente.
Il PEC 1864 è multistandard, supporta RTMP/RTP, RTSP unicast e
multicast, streaming per un decoder dedicato o indirizzi multicast utilizzando TS su UDP o RTP.

Link:
http://www.lynx-technik.com/products/yellobrik/video-conversion/pec-1864-3gbit-sdihdmi-h264-streamer-and-recorder/
Teracue presenta ICUE-GRID un video wall multi room basato interamente su IP
ICUE-GRID comando e controllo dei video wall IP
pubblicato lunedì, 5 ottobre 2015 da System Admin
Teracue presenta  ICUE-GRID un video wall  multi room basato interamente su IP
ICUE-GRID comando e controllo dei video wall IP
Teracue espande lo sviluppo della sua famiglia di prodotti ICUE-IPTV con ICUE- GRID, un nuovo Video Wall , multi sala, basato puramente su IP.
ICUE-GRID è una soluzione decentralizzata e scalabile quasi all'infinito.
Questo sistema offre un posizionamento dei video totalmente flessibile nel video wall , in qualsiasi risoluzione, fino al 4K.
La correzione integrata dei bezel permette di utilizzare monitor di qualsiasi formato.

ICUE-GRID utilizza la rete IP per distribuire i segnali. Ogni singolo display ha la propria unità di processo, montata sul retro. Le performance combinate di tutti questi processori distribuiti sono gestite dal controller IQUE-GRID tramite WEB che può essere istallato in un qualsiasi punto nella rete.
Questo intuitivo tool di gestione, insieme al processo distribuito GRID elimina la necessità di un controller
video wall tradizionale costoso.

I video live e i file on-demand possono essere semplicemente trascinati e incollati nel layout del ICUE-GRID .
Il video wall controllato ICUE-GRID va oltre la singola parete. Esso può controllare pareti multiple in vari ambienti. Esso può essere composto da un singolo schermo o da un insieme creativo di schermi .

ICUE-GRID è una logica evoluzione della collaudata famiglia ICUE-IPTV. L'uso conseguente dell'IP per la commutazione e i processi distribuiti spezza le barriere nella limitazione delle dimensioni dei video wall.
Noi abbiamo progettato ICUE-GRID in particolare per Conferenze in rete, Sale di controllo , "Digital Signage", eventi e presentazioni. In effetti in ogni situazione dove c'è la necessità di un layout multiviewer flessibile e reattivo, ICUE-GRID migliorerà drasticamente la rappresentazione ed inoltre permetterà di avere un risparmio finale.

Ora che l'A/V over IP e stato accettato come futuro nella distribuzione dei segnali, è il momento giusto per TERACUE di lanciare una ulteriore novità nel mercato del video IP.

ICUE-GRID utilizza a pieno il potenziale della rete per rimpiazzare le matrici A/V tradizionali.
Inoltre è completamente compatibile con il gamma dei prodotti TERACUE e si inserirà in molte delle implementazioni IPTV e A/V streaming.
Interviste live di qualità via Skype con l'opzione QuickLink-TX
QuickLink-TX
pubblicato mercoledì, 10 giugno 2015 da System Admin
Interviste live di qualità via Skype con l'opzione QuickLink-TX
Preannunciato al 2014 NAB Show, il software Skype-TX offre una elevata qualità audio e video è appositamente progettato per
collegare le emittenti e altri professionisti dei media con gli utenti Skype in tutto il mondo.

Per maggiori informazioni clicca qui
Network Electronics sponsor del TEAM "Fast Charge" Università "La Sapienza di Roma"
Read more...
pubblicato mercoledì, 9 ottobre 2013 da System Admin
Network Electronics sponsor del TEAM "Fast Charge"  Università  "La Sapienza di Roma"
Informiamo gli interessati che all'autodromo di Vallelunga sabato 12 ottobre e domenica 13 p.v. ci sarà l'esposizione della macchina di formula "Student Electric" del team "Fast Charge" dell'Università degli studi di Roma "La Sapienza" sponsorizzata da Network Electronics.

Saranno presenti anche vetture di "Superstars International Series", " FIA F3", "European Shampionship" e " GT Sprint International" che gareggieranno sul circuito.

Per maggiori informazioni sulla gara visitare il sito: www.vallelunga.it/it/motorsport/calendario-eventi
LYNX TECHNIK AG
Accordo tra Network Electronics e Lynx Technik AG
pubblicato mercoledì, 2 ottobre 2013 da System Admin
LYNX TECHNIK AG
NETWORK ELECTRONICS srl è lieta di annunciare di aver siglato un accordo di distribuzione con la Lynx Technik AG per la commercializzazione dei suoi prodotti sul territorio Italiano.
Lynx Technik AG è una società tedesca specializzata nello sviluppo di prodotti di alta qualità per i settori di mercato professionale e broadcast.
Il team di ricerca e sviluppo vanta un'esperienza decennale nei settori della post-produzione e trasmissione, questo gli ha permesso di vincere premi Emmy Awards per lo sviluppo di prodotti ingegneristici di eccezionale livello.
Lynx Technik AG ha 2 linee di prodotto:

Serie 5000
famiglia di schede, senza compromessi in grado di soddisfare tutte le esigenze degli operatori del broadcast.
Sono disponiblili le seguenti tipologie:
Conversioni Video, Conversioni Audio, Distribuzione Audio e Video (anche con F.O.), Change Over, Embedders e De-Embedders (anche con F.O.), Frame Syncronizers, Conversione in F.O. punto punto e CWDM, componenti ottici, audio delay, Test generators ecc.
Le schede posso essere alloggiate nei cestelli da 10 slot 2 RU con alimentazione singola o ridondata o in cestelli da 1 RU che contengono fino a 4 slots. Sono disponibili controller per la gestione locale o remota tramite computer o pannelli di controllo.

Serie Yellobrik
Un range di moduli che assicurano un rapporto prezzo/prestazioni ineguagliabile, anche in questo caso è disponibile una varietà di moduli per tutte le applicazioni:
Conversioni di formato, processo e distribuzione, trasporto su fibra ottica sia punto punto che CWDM, Test generator ecc.
I moduli possono essere utilizzati in configurazione stand alone o raggruppati su frame che permettono la condivisione di uno o due alimentatori.

La linea dei moduli è completata dal test generator TESTOR.
Il Testor è un generatore di test palmare in grado di riprodurre la maggior parte dei line pattern video oltre che segnali audio e word clock ad un prezzo molto competitivo.
